KLX 135 Pilot’s Guide Basic GPS Operation
4-3 Effective Date 3/94 006-08751-0000 Rev 0
Basic GPS Operation
Chapter 4
Fail is displayed, recycle power to the KLX 135. If the Self Test
page still displays Self-test Fail, the KLX 135 requires repair and
should not be used for navigation.
4. When you are ready to approve the Self-test page, press the F
button while the Ok? is flashing. If it happens not to be flashing,
press the
B
button and use the right outer knob to move the
cursor there.
5. The next page displayed will be
the Initialization page (figure 4-6).
Verify that the date displayed in
the top left corner of the
Initialization page is correct. The
KLX 135 has an internal battery
powered calendar/clock, so the date and time normally don’t
require setting. The battery has a life of approximately 3 years.
In addition, the KLX 135’s system date and time are automatical-
ly updated very precisely when at least one satellite is being
received. However, if for some reason the date or time are incor-
rect, it is necessary to enter the correct date or time so that the
KLX 135 can reach the navigation mode. The date must be cor-
rect and the time must be correct within ten minutes so that the
KLX 135 will start looking for the
correct satellites.
If the date is incorrect, rotate the
right outer knob counterclockwise
until the cursor is over the entire
date field (figure 4-7). Rotate the
right inner knob until the correct
day of the month is displayed
(figure 4-8). Then, move the cur-
sor to the month field by rotating
the outer knob one click
clockwise and change the month
as necessary. Use the same
methods to select the correct
year (figure 4-9). When the date
is correct, press
F
.
6. Verify that the time displayed in
the upper right corner of the
Initialization page is correct to
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
20 DEC 93 1415 UTC
WPT: Ref KIXD
N 38°49.91' 330°Fr
W 94°53.38'
Ok? 0.8nm
Figure 4-6
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
20 DEC 93 1415 UTC
WPT: Ref KIXD
N 38°49.91' 330°Fr
W 94°53.38' Ok? 0.8nm
Figure 4-7
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
07 --- -- 1415 UTC
WPT: Ref KIXD
N 38°49.91' 330°Fr
W 94°53.38' Ok? 0.8nm
Figure 4-8
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
07 JAN 94 1415 UTC
WPT: Ref KIXD
N 38°49.91' 330°Fr
W 94°53.38' Ok? 0.8nm
Figure 4-9
