Carrier 19XR,XRV Hermetic Centrifugal Liquid Chillers - Manual (Page 96)

96
Table 17B — 19XR Waterbox Cover Weights — SI (kg)
LEGEND
NOTE: Weight for NIH 2-Pass Cover, 150 psig is included in the heat exchanger weights shown in Table 6.
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 1 FRAME 2 FRAME 3
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 80 93 145 159 145 159
NIH, 2 Pass Cover, 150 psig 84 99 145 159 145 159
NIH, 3 Pass Cover, 150 psig 82 89 136 154 140 154
NIH/MWB End Cover, 150 psig 62 62 136 136 136 136
NIH, 1 Pass Cover, 300 psig 112 137 186 220 186 220
NIH, 2 Pass Cover, 300 psig 116 147 186 235 186 235
NIH, 3 Pass Cover, 300 psig 115 131 196 212 196 212
NIH/MWB End Cover, 300 psig 79 79 181 181 181 181
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 4 FRAME 5 FRAME 6
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 67 84 76 104 85 101
NIH, 2 Pass Cover, 150 psig 92 116 107 135 117 150
NIH, 3 Pass Cover, 150 psig 214 222 285 297 371 382
NIH/MWB End Cover, 150 psig 144 144 178 178 228 228
NIH, 1 Pass Cover, 300 psig 269 303 347 381 435 470
NIH, 2 Pass Cover, 300 psig 269 317 345 398 419 487
NIH, 3 Pass Cover, 300 psig 282 298 361 380 445 468
NIH/MWB End Cover, 300 psig 258 258 323 323 414 414
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 7 COOLER FRAME 7 CONDENSER
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 149 200 149 200
NIH, 2 Pass Cover, 150 psig 193 245 193 245
NIH, 3 Pass Cover, 150 psig 545 562 505 531
NIH/MWB End Cover, 150 psig 357 358 319 319
NIH, 1 Pass Cover, 300 psig 742 817 668 741
NIH, 2 Pass Cover, 300 psig 719 828 640 746
NIH, 3 Pass Cover, 300 psig 753 790 679 732
NIH/MWB End Cover, 300 psig 658 658 653 653
HEAT
EXCHANGER
WATERBOX
DESCRIPTION
FRAME 8 COOLER FRAME 8 CONDENSER
Standard
Nozzles
Flanged
Standard
Nozzles
Flanged
COOLER/
CONDENSER
NIH, 1 Pass Cover, 150 psig 189 224 189 224
NIH, 2 Pass Cover, 150 psig 241 311 241 311
NIH, 3 Pass Cover, 150 psig 711 738 652 679
NIH/MWB End Cover, 150 psig 607 607 407 407
NIH, 1 Pass Cover, 300 psig 1027 1102 844 914
NIH, 2 Pass Cover, 300 psig 984 1134 787 927
NIH, 3 Pass Cover, 300 psig 1031 1105 854 905
NIH/MWB End Cover, 300 psig 872 872 742 742
NIH — Nozzle-in-Head
MWB — Marine Waterbox
