Carrier 19XR,XRV Hermetic Centrifugal Liquid Chillers User Manual
Page 86
86
Table 12B — Thermistor Temperature (C) vs. Resistance/Voltage Drop
TEMPERATURE
(C)
PIC II
VOLTAGE DROP (V)
RESISTANCE
(Ohms)
–33
4.722
106 880
–32
4.706
100 260
–31
4.688
94 165
–30
4.670
88 480
–29
4.650
83 170
–28
4.630
78 125
–27
4.608
73 580
–26
4.586
69 250
–25
4.562
65 205
–24
4.538
61 420
–23
4.512
57 875
–22
4.486
54 555
–21
4.458
51 450
–20
4.429
48 536
–19
4.399
45 807
–18
4.368
43 247
–17
4.336
40 845
–16
4.303
38 592
–15
4.269
38 476
–14
4.233
34 489
–13
4.196
32 621
–12
4.158
30 866
–11
4.119
29 216
–10
4.079
27 633
–9
4.037
26 202
–8
3.994
24 827
–7
3.951
23 532
–6
3.906
22 313
–5
3.861
21 163
–4
3.814
20 079
–3
3.765
19 058
–2
3.716
18 094
–1
3.667
17 184
0
3.617
16 325
1
3.565
15 515
2
3.512
14 749
3
3.459
14 026
4
3.406
13 342
5
3.353
12 696
6
3.298
12 085
7
3.242
11 506
8
3.185
10 959
9
3.129
10 441
10
3.074
9 949
11
3.016
9 485
12
2.959
9 044
13
2.901
8 627
14
2.844
8 231
15
2.788
7 855
16
2.730
7 499
17
2.672
7 161
18
2.615
6 840
19
2.559
6 536
20
2.503
6 246
21
2.447
5 971
22
2.391
5 710
23
2.335
5 461
24
2.280
5 225
25
2.227
5 000
26
2.173
4 786
27
2.120
4 583
28
2.067
4 389
29
2.015
4 204
30
1.965
4 028
31
1.914
3 861
32
1.865
3 701
33
1.816
3 549
34
1.768
3 404
35
1.721
3 266
36
1.675
3 134
37
1.629
3 008
TEMPERATURE
(C)
PIC II
VOLTAGE DROP (V)
RESISTANCE
(Ohms)
38
1.585
2 888
39
1.542
2 773
40
1.499
2 663
41
1.457
2 559
42
1.417
2 459
43
1.377
2 363
44
1.338
2 272
45
1.300
2 184
46
1.263
2 101
47
1.227
2 021
48
1.192
1 944
49
1.158
1 871
50
1.124
1 801
51
1.091
1 734
52
1.060
1 670
53
1.029
1 609
54
0.999
1 550
55
0.969
1 493
56
0.941
1 439
57
0.913
1 387
58
0.887
1 337
59
0.861
1 290
60
0.835
1 244
61
0.811
1 200
62
0.787
1 158
63
0.764
1 118
64
0.741
1 079
65
0.719
1 041
66
0.698
1 006
67
0.677
971
68
0.657
938
69
0.638
906
70
0.619
876
71
0.601
836
72
0.583
805
73
0.566
775
74
0.549
747
75
0.533
719
76
0.518
693
77
0.503
669
78
0.488
645
79
0.474
623
80
0.460
602
81
0.447
583
82
0.434
564
83
0.422
547
84
0.410
531
85
0.398
516
86
0.387
502
87
0.376
489
88
0.365
477
89
0.355
466
90
0.344
456
91
0.335
446
92
0.325
436
93
0.316
427
94
0.308
419
95
0.299
410
96
0.291
402
97
0.283
393
98
0.275
385
99
0.267
376
100
0.260
367
101
0.253
357
102
0.246
346
103
0.239
335
104
0.233
324
105
0.227
312
106
0.221
299
107
0.215
285
