CL-12
UNIT-MOUNTED VFD CONFIGURATION SHEET
*Variable by job — refer to component nameplates and labels.
DESCRIPTION PARAMETER RANGE DEFAULT COMMENTS
Maximum Speed P.004 15 to H.022 * Job Sheet; 60 for 60 Hz and 50 for 50 Hz
Speed Display Scaling P.028 10 to 999 * Job Sheet; 60 for 60 Hz and 50 for 50 Hz
Motor Voltage H.000 100 to 690 * Selected line voltage
Frequency H.001 30 to 200 * 60 Hz = 60, 50 Hz = 50
Motor Amps H.002 Power Module Dependent * Selected motor 100% amps
Line Voltage H.021 300 to 565 * Selected line voltage
Over Frequency Limit H.022 30 to 210 * 60 Hz = 69, 50 Hz = 57
