Carrier 19XR,XRV Hermetic Centrifugal Liquid Chillers - Manual (Page 93)

93
Table 14 — 19XR Additional Data for Marine Waterboxes*
*Add to heat exchanger data for total weights or volumes.
NOTES:
1. Weight adder shown is the same for cooler and condenser of equal frame size.
2. For the total weight of a vessel with a marine waterbox, add these values to the heat
exchanger weights (or volumes).
Table 15 — Compressor Weights
*Transmission weight does not include rotor, shaft, and gear.
HEAT EXCHANGER
FRAME, PASS
ENGLISH SI
Psig
Rigging Weight
(lb)
Water Volume
(gal)
kPa
Rigging Weight
(kg)
Water Volume
(L)
FRAME 2, 1 AND 2 PASS 150 730 84 1034 331 318
FRAME 2, 2 PASS 150 365 42 1034 166 159
FRAME 3, 1 AND 2 PASS 150 730 84 1034 331 317
FRAME 3, 2 PASS 150 365 42 1034 166 159
FRAME 4, 1 AND 3 PASS 150 1060 123 1034 481 465
FRAME 4, 2 PASS 150 530 61 1034 240 231
FRAME 5, 1 AND 3 PASS 150 1240 139 1034 562 526
FRAME 5, 2 PASS 150 620 69 1034 281 263
FRAME 6, 1 AND 3 PASS 150 1500 162 1034 680 612
FRAME 6, 2 PASS 150 750 81 1034 340 306
FRAME 7, 1 AND 3 PASS 150 2010 326 1034 912 1234
FRAME 7, 2 PASS 150 740 163 1034 336 617
FRAME 8, 1 AND 3 PASS 150 1855 406 1034 841 1537
FRAME 8, 2 PASS 150 585 203 1034 265 768
FRAME 2, 1 AND 3 PASS 300 860 84 2068 390 318
FRAME 2, 2 PASS 300 430 42 2068 195 159
FRAME 3, 1 AND 3 PASS 300 860 84 2068 390 317
FRAME 3, 2 PASS 300 430 42 2068 195 159
FRAME 4, 1 AND 3 PASS 300 1210 123 2068 549 465
FRAME 4, 2 PASS 300 600 61 2068 272 231
FRAME 5, 1 AND 3 PASS 300 1380 139 2068 626 526
FRAME 5, 2 PASS 300 690 69 2068 313 263
FRAME 6, 1 AND 3 PASS 300 1650 162 2068 748 612
FRAME 6, 2 PASS 300 825 81 2068 374 306
FRAME 7, 1 AND 3 PASS 300 3100 326 2068 1406 1234
FRAME 7, 2 PASS 300 1830 163 2068 830 617
FRAME 8, 1 AND 3 PASS 300 2745 405 2068 1245 1533
FRAME 8, 2 PASS 300 1475 203 2068 766 768
COMPONENT
FRAME 2
COMPRESSOR
WEIGHT
FRAME 3
COMPRESSOR
WEIGHT
FRAME 4
COMPRESSOR
WEIGHT (Without
Split Ring Diffuser)
FRAME 4
COMPRESSOR
WEIGHT (With
Split Ring Diffuser)
FRAME 5
COMPRESSOR
WEIGHT
lb kg lb kg lb kg lb kg lb kg
SUCTION ELBOW 50 23 54 24 175 79 175 79 400 181
DISCHARGE ELBOW 60 27 46 21 157 71 157 71 325 147
TRANSMISSION* 320 145 730 331 656 298 656 298 1000 454
SUCTION HOUSING 300 136 350 159 446 202 810 367 1200 544
IMPELLER SHROUD 35 16 80 36 126 57 200 91 250 113
COMPRESSOR BASE 1260 571 1050 476 1589 721 2022 917 3695 1676
DIFFUSER 35 16 70 32 130 59 130 59 300 136
OIL PUMP 125 57 150 68 150 68 150 68 185 84
MISCELLANEOUS 100 45 135 61 144 65 200 91 220 100
TOTAL WEIGHT
(Less Motor and Elbows)
2300 1043 2660 1207 3712 1684 4548 2063 6850 3107
