4.11.6.
Firmware Upgrade
The Firmware Upgrade page is used to update phone to new firmware releases.
Login → Maintenance → Firmware Upgrade
Figure 28 Firmware Upgrade
To upgrade the firmware:
1.
Select ‘FTP’. Firmware upgrade through HTTP is not supported as of yet.
2.
Enter the FTP Server IP Address, Username
17
, and Password
18
for authentication. If the
username and password is preferred to be retained for a future upgrade, select the Save Username
and Password check box.
3.
In the Filename box, enter the filename with its complete path. If the file is saved in the home
directory of the ftp server, then enter ONLY the filename and NOT the complete filepath. The
filename is generally in the format of (EVP_A_B_C_D). If the firmware upgrade file is not in the
home directory of the ftp server, then this filename needs to be prefixed with directory relative to the
FTP root directory. For example, /ftp/EVP_images/EVP_1_0_0_0). Consult the Administrator for
FTP settings.
17
The maximum number of characters in username is 30.
18
The maximum number of characters in password is 30.
