4.5.5. Paging Settings
The VOIP-600 Series Phone can be used as a paging device by a WEBS Contact® Server. The page can be
output through either the built-in hands-free speaker or the line level output.
Login → VoIP → Paging Settings
Figure 11 Paging Settings
To configure paging settings:
1. Select Speaker or Line Level Output to send the incoming audio page to the built-in hands-free speaker
or the line level output. The speaker option is only available for device modes with an “S” designator (e.g.,
1BS, 4BHSK).
2. Click the drop-down menu to adjust the Output Gain for all incoming pages before sending to the
selected audio paging output. Each level adjustment corresponds to approximately 3dB.
3. Click ‘Yes’ to Automatically activate paging for inbound phone calls to the VOIP-600.
4. Enter the Keycodes to activate and deactivate paging during an inbound phone call to the VOIP-
600.
5. The phone displays Unregistered or Registered @ for
Registration Status on the WEBS Contact® Server.
1
2
7
4
3
4
5
6
