REAR CLAMP ASSEMBLY

STEP 1
Install Cotter Pin (A) into Handle Pivot Tube (B)
and slide on Plastic Bushing (C)

(A)

(B)

(C)

STEP 2
Insert Handle Pivot Tube (A)
into Pivot Bracket (B) at the
rear of the rail, until the
bushing is fully seated.

(A)

(B)
