Fastener chart – WEATHER GUARD Model 254 EZ-GLIDE® Clamp Kit, Universal, Driver Side User Manual
Page 3
3
4
5/16 18 x 2 3/4 Hex Hd. Bolt
2
Bushing (See Page 2)
1
Cotter Pin
2
5/16-18 x 2-1/2" Carriage Bolt
1
5/16-18 x 2-1/2" Hex Hd. Bolt
1
Handle Pivot Ball W/ Allen Screw
(See Page 2)
5/16-18 x 2-3/4" Hex Hd. Bolt
5/16-18 x 2-1/2" Hex Hd. Bolt
5/16-18 x 2" Hex Hd. Bolt
5/16-18 x 1" Hex Hd. Bolt
5/16-18 x 2-1/2" Carriage Bolt
Cotter Pin
5/16-18 Nylon Lock Nut
5/16" Flat Washer
FASTENER CHART
