PNOZ s4
Operating Manual PNOZ s4
21396-EN-12
16
Conventional ther-
mal current while
loading several
contacts
750104
750134
751104
751134
Ith per contact at UB
AC
Conv. therm. cur-
rent with 1 con-
tact
–
6,00 A
–
6,00 A
Conv. therm. cur-
rent with 2 con-
tacts
–
6,00 A
–
6,00 A
Conv. therm. cur-
rent with 3 con-
tacts
–
4,50 A
–
4,50 A
Ith per contact at UB
DC
Conv. therm. cur-
rent with 1 con-
tact
6,00 A
6,00 A
6,00 A
6,00 A
Conv. therm. cur-
rent with 2 con-
tacts
6,00 A
6,00 A
6,00 A
6,00 A
Conv. therm. cur-
rent with 3 con-
tacts
5,00 A
4,50 A
5,00 A
4,50 A
Times
750104
750134
751104
751134
Switch-on delay
With automatic
reset typ.
170 ms
170 ms
170 ms
170 ms
With automatic
reset max.
300 ms
300 ms
300 ms
300 ms
With automatic
reset after power
on typ.
350 ms
350 ms
350 ms
350 ms
With automatic
reset after power
on max.
600 ms
600 ms
600 ms
600 ms
With manual reset
typ.
40 ms
40 ms
40 ms
40 ms
With monitored
reset with rising
edge typ.
35 ms
35 ms
35 ms
35 ms
With monitored
reset with rising
edge max.
50 ms
50 ms
50 ms
50 ms
With monitored
reset with falling
edge typ.
55 ms
55 ms
55 ms
55 ms
With monitored
reset with falling
edge max.
70 ms
70 ms
70 ms
70 ms
