PNOZ s4
Operating Manual PNOZ s4
21396-EN-12
14
Electrical data 750104 750134 751104 751134
Dual-channel with
detection of
shorts across
contacts at UB
AC
– 30 Ohm – 30 Ohm
Min. input resistance
at power-on
110 Ohm 110 Ohm 110 Ohm 110 Ohm
Voltage at
Input circuit DC 24,0 V 24,0 V 24,0 V 24,0 V
Reset circuit DC 24,0 V 24,0 V 24,0 V 24,0 V
Feedback loop
DC
24,0 V 24,0 V 24,0 V 24,0 V
Current at
Input circuit DC 50,0 mA 50,0 mA 50,0 mA 50,0 mA
Reset circuit DC 50,0 mA 50,0 mA 50,0 mA 50,0 mA
Feedback loop 50,0 mA 50,0 mA 50,0 mA 50,0 mA
Number of output
contacts
Instantaneous
safety contacts
(N/O)
3 3 3 3
Auxiliary contacts
(N/C)
1 1 1 1
Inputs 750104 750134 751104 751134
Number 2 2 2 2
Semiconductor
outputs
750104 750134 751104 751134
Number 1 1 1 1
Voltage 24,0 V 24,0 V 24,0 V 24,0 V
Current 20 mA 20 mA 20 mA 20 mA
Relay outputs 750104 750134 751104 751134
Max. short circuit
current IK
1 kA 1 kA 1 kA 1 kA
Utilisation category
In accordance
with the standard
EN 60947-4-1 EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
Auxiliary contacts,
AC1 at
240 V 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A 0,01 A
Max. current 6,0 A 6,0 A 6,0 A 6,0 A
Max. power 1500 VA 1500 VA 1500 VA 1500 VA
Auxiliary contacts,
DC1 at
24 V 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A 0,01 A
Max. current 6,0 A 6,0 A 6,0 A 6,0 A
Max. power 150 W 150 W 150 W 150 W
Safety contacts,
AC1 at
240 V 240 V 240 V 240 V
Max. current 6,0 A 6,0 A 6,0 A 6,0 A
