PNOZ s4
Operating Manual PNOZ s4
21396-EN-12
13
Technical details
General 750104 750134 751104 751134
Approvals CCC, CE, GOST,
KOSHA, TÜV, cU-
Lus Listed
CCC, CE, GOST,
KOSHA, TÜV, cU-
Lus Listed
CCC, CE, GOST,
KOSHA, TÜV, cU-
Lus Listed
CCC, CE, GOST,
KOSHA, TÜV, cU-
Lus Listed
Electrical data 750104 750134 751104 751134
Supply voltage
Voltage 24 V 48 - 240 V 24 V 48 - 240 V
Type DC AC/DC DC AC/DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply
(AC)
– 5,0 VA – 5,0 VA
Output of external
power supply
(DC)
2,5 W 2,5 W 2,5 W 2,5 W
Frequency range
AC
– 50 - 60 Hz – 50 - 60 Hz
Residual ripple
DC
20 % 160 % 20 % 160 %
Continuous duty 100 % 100 % 100 % 100 %
Max. inrush current
impulse
A1 0,50 A – 0,50 A –
Pulse duration 5,0000 ms – 5,0000 ms –
Reset circuit 0,20 A 0,20 A 0,20 A 0,20 A
Feedback loop 0,20 A 0,20 A 0,20 A 0,20 A
Max. overall cable
resistance Rlmax
Single-channel at
UB DC
30 Ohm 30 Ohm 30 Ohm 30 Ohm
Single-channel at
UB AC
– 30 Ohm – 30 Ohm
Dual-channel
without detection
of shorts across
contacts at UB
DC
60 Ohm 30 Ohm 60 Ohm 30 Ohm
Dual-channel
without detection
of shorts across
contacts at UB
AC
– 30 Ohm – 30 Ohm
Dual-channel with
detection of
shorts across
contacts at UB
DC
30 Ohm 30 Ohm 30 Ohm 30 Ohm
