PNOZ s4
Operating Manual PNOZ s4
21396-EN-12
15
Relay outputs
750104
750134
751104
751134
Min. current
0,01 A
0,01 A
0,01 A
0,01 A
Max. power
1500 VA
1500 VA
1500 VA
1500 VA
Safety contacts,
DC1 at
24 V
24 V
24 V
24 V
Max. current
6,0 A
6,0 A
6,0 A
6,0 A
Min. current
0,01 A
0,01 A
0,01 A
0,01 A
Max. power
150 W
150 W
150 W
150 W
Utilisation category
In accordance
with the standard
EN 60947-5-1
EN 60947-5-1
EN 60947-5-1
EN 60947-5-1
Auxiliary contacts,
AC15 at
230 V
230 V
230 V
230 V
Max. current
5,0 A
3,0 A
5,0 A
3,0 A
Auxiliary contacts,
DC13 (6 cycles/
min) at
24 V
24 V
24 V
24 V
Max. current
5,0 A
4,0 A
5,0 A
4,0 A
Safety contacts,
AC15 at
230 V
230 V
230 V
230 V
Max. current
5,0 A
3,0 A
5,0 A
3,0 A
Safety contacts,
DC13 (6 cycles/
min) at
24 V
24 V
24 V
24 V
Max. current
5,0 A
4,0 A
5,0 A
4,0 A
Contact fuse protec-
tion, external safety
contacts
In accordance
with the standard
EN 60947-5-1
EN 60947-5-1
EN 60947-5-1
EN 60947-5-1
Blow-out fuse,
quick
10 A
6 A
10 A
6 A
Blow-out fuse,
slow
6 A
4 A
6 A
4 A
Circuit breaker,
24V AC/DC, char-
acteristic B/C
6 A
4 A
6 A
4 A
Contact fuse protec-
tion, external auxilia-
ry contacts
Blow-out fuse,
quick
10 A
6 A
10 A
6 A
Blow-out fuse,
slow
6 A
4 A
6 A
4 A
Circuit breaker,
24 V AC/DC,
characteristic B/C
6 A
4 A
6 A
4 A
Contact material
AgCuNi + 0,2 µm
Au
AgCuNi + 0,2 µm
Au
AgCuNi + 0,2 µm
Au
AgCuNi + 0,2 µm
Au
