PNOZ s3
Operating Manual PNOZ s3
21395-EN-10
13
Relay outputs 750103 751103
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Safety contacts, AC1 at 240 V 240 V
Max. current 6,0 A 6,0 A
Min. current 0,01 A 0,01 A
Max. power 1500 VA 1500 VA
Safety contacts, DC1 at 24 V 24 V
Max. current 6,0 A 6,0 A
Min. current 0,01 A 0,01 A
Max. power 150 W 150 W
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Safety contacts, AC15 at 230 V 230 V
Max. current 5,0 A 5,0 A
Safety contacts, DC13 (6 cycles/
min) at
24 V 24 V
Max. current 5,0 A 5,0 A
Contact fuse protection, external
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Blow-out fuse, quick 10 A 10 A
Blow-out fuse, slow 6 A 6 A
Circuit breaker, 24V AC/DC,
characteristic B/C
6 A 6 A
Conventional thermal current 6,0 A 6,0 A
Contact material AgCuNi + 0,2 µm Au AgCuNi + 0,2 µm Au
Times 750103 751103
Switch-on delay
With automatic reset typ. 170 ms 170 ms
With automatic reset max. 300 ms 300 ms
With automatic reset after power
on typ.
350 ms 350 ms
With automatic reset after power
on max.
600 ms 600 ms
With manual reset typ. 40 ms 40 ms
With monitored reset with rising
edge typ.
35 ms 35 ms
With monitored reset with rising
edge max.
50 ms 50 ms
With monitored reset with falling
edge typ.
55 ms 55 ms
With monitored reset with falling
edge max.
70 ms 70 ms
