Semiconductor outputs 750102 751102
Number 1 1
Voltage 24,0 V 24,0 V
Current 20 mA 20 mA
Relay outputs 750102 751102
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Auxiliary contacts, AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 6,0 A 6,0 A
Max. power 1500 VA 1500 VA
Auxiliary contacts, DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 6,0 A 6,0 A
Max. power 150 W 150 W
Safety contacts, AC1 at 240 V 240 V
Max. current 6,0 A 6,0 A
Min. current 0,01 A 0,01 A
Max. power 1500 VA 1500 VA
Safety contacts, DC1 at 24 V 24 V
Max. current 6,0 A 6,0 A
Min. current 0,01 A 0,01 A
Max. power 150 W 150 W
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Auxiliary contacts, AC15 at 230 V 230 V
Max. current 5,0 A 5,0 A
Auxiliary contacts, DC13 (6 cy-
cles/min) at
24 V 24 V
Max. current 5,0 A 5,0 A
Safety contacts, AC15 at 230 V 230 V
Max. current 5,0 A 5,0 A
Safety contacts, DC13 (6 cycles/
min) at
24 V 24 V
Max. current 5,0 A 5,0 A
Contact fuse protection, external
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Blow-out fuse, quick 10 A 10 A
Blow-out fuse, slow 6 A 6 A
Circuit breaker, 24V AC/DC,
characteristic B/C
6 A 6 A
Contact fuse protection, external
auxiliary contacts
Blow-out fuse, quick 10 A 10 A
Blow-out fuse, slow 6 A 6 A
Circuit breaker, 24 V AC/DC,
characteristic B/C
6 A 6 A
