LogicPLUS-S Two-Wire Controller

PROGRAMMinG The LogicPLUS-S 42 and LogicPLUS-S 128 COnTROLLeRS

The LogicPLUS-S Controllers are so easy to program because the four sets of black up/down

arrow buttons correspond to whatever is directly above them in the display. You can toggle between

ON and OFF, set hours, minutes, and seconds, or even select program numbers, valve numbers, and

start times simply by using these up/down buttons located directly under their functions. The square

Function button located to the right of the arrow buttons will access the functions listed when the dial

is turned to the numbered position stated by each function.

The controller programming consists of 8 buttons to control the display, a twelve position rotary switch

and a special function key for more special options. The 8 buttons that control the display are located

directly below the portion of the display they control. Each set (two buttons) of buttons operates the

display up or down for ease of getting to the function, number, valve or time desired. For ease of ex-

planation, the following terminology will be used throughout these instructions. The set of buttons to

the far left will be button

set 1, directly right of these will be set, directly right of set 2 will be set 3 and

the last set or far right set will be

set 4, the special Function button in the upper right of the control

panel, will be referred to as

set 5.

nOTe: See diagram page 9-26

The main rotary dial has 12 positions just like the numbered hour positions on a clock 1-12. The rotary

switch consists of the following positions and functions:

nOTe:
When you first install your LogicPLUS-S 42 or LogicPLUS-S 128 controller, use the Master

Clear feature to clear all possible information stored in the unit. Put dial in position 10, press

top right Up/down key set 4 under “CLR” OFF. display will change, then press top right Up/

down key set 4 under “Master yes” again. Controller will automatically clear ALL program-

mable data except current date and time.
