LogicPLUS-S Two-Wire Controller 7
LogicPLUS-S installation “do’s & don’ts”
For Warranty To Be Valid, installation Must Comply To All instructions Below
1. Use only LP-RP Receivers (Gray Molded Box) with the LogicPLUS-S Controllers (LP-42, LP-
128 and Uni-2 Plus). dO nOT use the L-RP (Black Molded Box) Receivers with the Logic
PLUS-S Controllers. dO nOT use the LP-RP (Gray Box) Receiver with the Logic 1, Logic 2,
Logic 3 or Uni-2 Controller.
2. Branching and Teeing of two wire path is permitted with LogicPLUS-S, but should be well
planned and minimized with care given using only waterproof DBC-BR splice kits.
All wire connection/splices are to be made in a valve box. dO nOT “direct” bury
connection/splices.
3. LogicPLUS-S receivers must be directly attached to the 2 wire path; red wires to field wires,
black wires to solenoid (See #4).
4. Wire Connections
A. All field wiring Connections of LogicPLUS-S Receiver Red Wires (1 each to each of field
wires) to field wires must use the enclosed DBC-BR splice kits. See instructions on back.
dO nOT USe PRe-FiLLed GeL TyPe WiRe nUTS.
B. All receiver to Valve Solenoid Connections must be waterproof, using “dry type” wire
connectors (Hit Products DBC series or 3M™ DBY/DBR series™) and/or soldered and then
installed in waterproof housings. dO nOT USe PRe-FiLLed GeL TyPe WiRe nUTS.
5. dO nOT install the LogicPLUS-S Controller, its Receivers or any LogicPLUS-S Field Wire
within 15 feet of any high voltage current that may cause electrical interference such as;
electrical panels, meters, pumps, equipment or controls.
6. Use with standard 24 VAC solenoids only. dO nOT use any with low power/diode bridge type
solenoids.
7. Use different colored field wires for each wire in each two-wire path.
8. LogicPLUS-S provides 4 separate field outputs. Line 1, Line 2, Line 3 and Line 4.
dO nOT mix the wiring.
