LogicPLUS-S Two-Wire Controller 27
1. Set the controller in the OFF position. Turn the rotary switch to position 11
(Rain Off/Auto On/Off) use the top right arrow key set 4 to turn the setting from ON to OFF.
This will stop any program that is running and prevent any form starting while programming
receivers.
2.
disconnect the field wires.
3. Set the Rotary switch to the “Run” position. Position 12.
4. Press the “Function” key to access the “Set Decoder ID” screen.
5. Connect the 3.5mm plug wire to the 3.5mm Jack Connector on bottom of board.
(Programming Port)
6. Connect each of the red wire on receiver with each of the alligator clips.
7.
Be sure black receiver wires are not touching.
8. Using the arrow keys corresponding directly underneath the ID number in the display (set 3)
select the desired number or MSTRA, MSTRB, MSTRC or Fert, for a Master or Fertigation
receiver. The Master and Fertigation choices are found by scrolling through the station number.
Use the down arrow key to quickly access the Master and Fert settings.
9. Press the arrow key corresponding to “Enter” on the display (right up set 4).
10. The LED on the receiver will flash three (3) times.
11. Remove the red leads.
12. Install “Receiver Number Identification Tag” (see below listed instructions.)
If programming more receivers repeat from step 5. (see “Receiver Programming Leads” below.)
13. To end programming press “Function” key to return to “Run.” Controller will not resume “Run”
automatically.
14. Re-connect field wires.
15.
Set the Controller back to On to resume Auto Programming. Rotate the dial to position 11.
Use the top right arrow key to turn the setting from OFF to ON.
Position 12
LogicPLUS-S Receiver Programming instructions
When programming a receiver with a controller that is installed with the field wires connected:
