Page 40
36
Troubleshooting
Welch Allyn Connex CSK software
Software modules in a simple network configuration, wireless or Ethernet
Software modules in a USB configuration
DC
Server
Related illustration:
“Client-server network configuration, wireless or Ethernet”
DCP
XML
Server
Workstation
DC
Related illustration:
USB cable
XML
(Optional)
