Vintage Cellars Ceiling Mount - Manual (Page 5)

www.whisperkool.com | Page 3
2 x 1.50 Knockout
(Both Sides)
2 x 0.84 THRU
2 x 1.50 Knockout
2 x 0.84 THRU
D
C
B
A A
B
C
D
1 2 3 4 5 6 7 8
8 7 6 5 4 3 2 1
PROPRIETARY AND CONFIDENTIAL
NEXT ASSY USED ON
APPLICATION
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
INTERPRET GEOMETRIC
TOLERANCING PER:
MATERIAL
FINISH
DRAWN
CHECKED
ENG APPR.
MFG APPR.
Q.A.
COMMENTS:
DATE NAME
TITLE:
SIZE
B
DWG. NO. REV
WEIGHT: SCALE: 1:6
UNLESS OTHERWISE SPECIFIED:
SHEET 1 OF 1
DO NOT SCALE DRAWING
1
Sheet 1
1-556000 Center Ceiling Mount
Knockout Locations
F. Pfaller
KNOCKOUT LOCATIONS
Side View of Evaporator Unit
Top View of Evaporator Unit
1.5”
2.5”
3”
5.55”
5.55”
14.1”
1.55”
Top View
Side View
1.75”
1.75”
13.25”
13.25”
20.75”
20.75”
35.75”
35.75”
12.65”
6.58”
1.5”
4.57” 4.29”
2”
12.65”
6.36”
