Minimum Tools Needed:

Fully Exposed

Mounting Option

Flush Mount

Mounting Option

Choose a Mounting

Option suitable

for the installation

location.

Partially Recessed

Mounting Option

Locate the desired installation location. Using a stud finder, locate the ceiling

joists on either side of the center point. Cut and frame an opening in the

ceiling measuring 14.5” x 36”. Make sure the framing is sufficient to support

the weight of the cooling unit. It is highly recommended to use only the

mounting locations provided.  These locations ensure that the installer

will not drill into any copper or electrical within the system.

Hammer

Saw

Phillips Head #2

Screwdriver

PREPARING THE INSTALLATION LOCATION

T-Square

1

2

3

4

12.65”

12.65”

5.75”

6.9”

6.9”

5.75”
