Quick reference guide, Top view bottom view – Vintage Cellars Ceiling Mount User Manual
Page 4
Page 2 | 1-800-343-9463
WCM
033114
QUICK REFERENCE GUIDE
Top View
Bottom View
Mounting Bracket (Paintable)
Supply and Return Grille (Paintable)
Evaporator Unit (Fan Coil Unit)
Electrical Knockouts
Line Set Knock Out (x6)
Note: The unit comes black. The mounting bracket and front grille
are paintable, enabling you to match your desired color.
Top Panel
Electrical Knockout
Options
Line Set Knockout
Options
