Rice Lake 920i Based Truck In/Out System User Manual
Page 5
Introduction and System Overview
1
1.0
Introduction and System Overview
This manual provides information on using a truck in/out weighing program (PN 77297) for manual truck
transactions using Rice Lake Weighing System’s 920i digital weight indicator. Stored IDs let you keep a database of
truck IDs, customer product and project information, and weigh-in weights in the indicator’s memory and are
accessed by simply scrolling through the
Supervisor
main menu using the down arrow on the 920i. The 920i can
automatically store up to 100 truck ID’s and tare weights, 950 customers, 1000 products, and 1000 projects.
While this manual gives basic information about this program, it only addresses those settings that are important to the
operation of the truck in/out program. For further information on the installation, configuration, and operation of the
920i, consult the 920i Installation Manual, PN 67887.
To install the truck in/out program onto your 920i programmable indicator, it must be in configuration mode before
the
.cod
file can be sent. You can send the
.cod
file directly from
iRev
by using the
Download Configuration...
selection
on the
Communications
menu and specifying that you want to send the
.cod
file.
The following main menu screen is shown.
Figure 1-1. Main Screen
The main screen consists of general information that will be added as information is accessed from the database.
All of the softkeys access additional function parameters and are explained in further detail in the following sections.
Softkey
Description
Weigh
Select this softkey to do a single weighment
Weigh In
Allows truck ID entry; generates weigh-in ticket
Weigh Out
Allows truck ID entry; generates weigh-out ticket
Scale Select
For multi-scale applications, provides a prompt to enter the scale number to be displayed
Supervisor Mode
Allows information to be added to the database
Table 1-1. Softkey Descriptions
Weigh
Weigh Out
