8 920i Based Truck In/Out Weigh Program
2.5.6 Format Ticket
1. Format a ticket by selecting the Format Ticket softkey screen as shown in Figure 2-8 and select the print
format to be edited. The following screen is displayed.
Figure 2-11. Format Ticket Select
2. Choose the type of ticket format type by using the numeric keypad to select 1 , 2 , or 3 . Figure 2-12 illustrates an
example of the weigh ticket format screen.
Figure 2-12. Format Ticket Screen
3. Enter information and press enter to save your entry.
This can also be done through the Database Editor. To view the database rows/columns for the sample ticket
shown below, see Appendix 7.2.
Exit to
Weigh
10/22/07 08:05AM SCALE #1
1
2
3
4
7
6
5
Format
Format
Format
Enter Selection Number
Menu/
Cancel
Weigh Ticket
Weigh In Ticket
Weigh Out Ticket
Choose Type to Format
Home Cancel
10/22/07 08:05AM SCALE #1
End
Weigh Ticket Format
Enter Row
Press Cancel to End
Note
Table 1-1. Data Fields Parameters
