Ch1 Fuel = 47%
Ch2 Fuel = 55%
Results of unique FMA algorithm that
determines pack “fuel level.” Data is also
used to calculate correct C rate during
1/2/3C charging.
Ch1 Pack = 15.772V
Ch2 Pack = 15.761V
Total pack voltage(s).
Ch1 42mAh In
Ch2 40mAh In
mAh put back into pack(s) during charging.
1:3.956V 2:3.956V
3:3.956V 4:3.956V
Individual cell voltages.* “:” indicates Ch1
screen auto scrolls to show all cells:
5=3.966V 6=3.966V
7=3.966V 8=3.966V
Individual cell voltages.* “=” indicates Ch2
1:12.3mΩ 2:13.2
3:12.1mΩ 4:14.2
Individual cell internal resistances in
milliohms.*† “:” indicates Ch1
screen auto scrolls to show all cells:
5=11.8mΩ 6=13.5
7=12.4mΩ 8=12.6
Individual cell internal resistances in
milliohms.*† “=” indicates Ch2
*Cells are numbered from 1 through n, where 1 is the first cell in the pack connected to Ch1, and n is the last cell in the pack
(if only one pack is being charged) or the last cell in the pack connected to Ch2 (if two packs are being charged).
†For the charger to calculate internal resistances, pack must be at less than 80% fuel level at start. Internal resistances will
be available for display after about 12 minutes of charging, and will be periodically updated after that.
5. Note, when you press and hold the START/STOP button to initiate a charge or storage operation
(step 2 above), you are actually starting a charge “session”. During a session, the data is logged to the
charger’s memory, the LCD, and to the CCS (if connected to the PC). When the charger is allowed to
finish the operation, the LCD will read, e.g.,
LiPo [BAL] DONE
To end the charge session and clear logged data: Press the START/STOP button for one second.
The charger flashes CHARGER STOPPED then displays the Preset Menu.
Note: Pack data is lost when you end the charge session, so if you want to see it, cycle through the saved
data by pressing the MODE button before pressing and holding the START/STOP button.
To cancel charging at any time: Press and hold the START/STOP button for one second. The
charger flashes CHARGER STOPPED then displays the Preset Menu.
Note: Pack data is lost when you end the charge session, so if you want to see it, cycle through the saved
data by pressing the MODE button before pressing and holding the START/STOP button.
Options Menu Explained
In addition to the charger’s Preset Menu, and Main Menu, there is also an Options Menu available for
altering basic charger settings using the charger’s interface. The Options Menu is accessed by pressing
and holding the MODE button while you power up the charger.
