Applying power to the charger
To apply power to the charger: Connect the charger to a 10V to 32V DC power supply, field battery
or car battery. If your bench power supply is equipped with banana jacks for output, you can remove
the plier clips from the charger’s input cables and plug the cables directly into the power supply jacks.
When the charger is powered up, it displays the following “Welcome” screen:
Cellpro 10XP
[firmware version]*
Press the MODE button one time to advance to the “Preset Menu”
Preset 1
[chem] [BAL]
@ [charge current]*
Press the MODE button repeatedly to scroll through and view/select the Cellpro 10XP’s 10 presets,
one at a time.
*Information in square brackets varies.
Introduction to presets
As shipped from the factory, the charger has ten presets. The presets are displayed in the “Preset Menu”
and display in the charger’s LCD as follows:
Preset Name/Settings Description
Preset 1
LiPo BAL @ 1.0C Designed for a single 1s-10s LiPo battery, balance
charged at AUTO 1.0C.
P2 Dual Channels
LiPo BAL @ 1.0C Designed for two, 1s-5s LiPo batteries, balance
charged at AUTO 1.0C.
Preset 3
LiPo BAL @ STORE Designed to automatically storage charge or discharge
LiPo batteries to 3.8v per cell for safe storage.
Preset will charge using AUTO 1.0C or discharge using
1A internal balance circuits.
Preset 4
LiPo 2sU @ 1.0A Designed for one 2s LiPo, unbalance charged at 1.0A
manual rate setting.
Preset 5
A123 BAL @ 4.6A
Designed for 1s-10s A123 battery, balance charged at
4.6A manual rate setting.
P6 Dual Channels
A123 BAL @ 4.6A Designed for two, 1s-5s A123 batteries, balance
charged at 4.6A manual rate setting.
Preset 7
A123 2sU @ 4.6A Designed for one 2s A123, unbalance charged at 4.6A
manual rate setting.
Preset 8
NiCd 8mV @ 1.0A Designed for 1-26 cell NiCd, non balance charged, peak
detection, 8mV fallback at 1.0A manual rate setting.
Preset 9
NiMH 5mV @ 1.0A Designed for 1-26 cell NiMH, non balance charged, peak
detection, 5mV fallback at 1.0A manual rate setting.
Preset 10
LEAD 12V @ 3.0A Designed for 12V Lead Acid Battery, non balance
charged at 3.0A manual rate setting.
When power is applied, the charger always initializes to the last preset used for charging. If you altered
the charge settings for a preset at the charger (as described in “Changing a preset,” later in this manual),
those changes are retained when the charger is disconnected from power, and will be reapplied when the
charger is powered up again.
“Selecting a preset” and “Changing a preset,” in the next section, provide additional information.
