H P - 1 7 5 / 2 2 5 I N S T A L L A T I O N M A N U A L
GLAZING OPTIONS & ACCESSORIES CHART
HP-175 & HP-225
3/16"
NHP-30
HP-119
HP-213
HP-8
HP-10
HP-17
NHP-1003
1 /4"
NHP-5A
HP-119
HP-213
HP-8
HP-10
HP-17
NHP-1003
5/16"
NHP-33
HP-119
HP-213
HP-8
HP-10
HP-17
NHP-1003
9/16"
NHP-30
HP-163
HP-213
HP-8
HP-10
HP-17
NHP-1003
5/8"
NHP-5A
HP-163
HP-213
HP-8
HP-10
HP-17
NHP-1003
11/16"
NHP-33
HP-163
HP-213
HP-8
HP-10
HP-17
NHP-1003
15/16"
NHP-30
------
HP-213
HP-8
HP-10
HP-17
NHP-1003
1"
NHP-5A
------
HP-213
HP-8
HP-10
HP-17
NHP-1003
1 1/16"
NHP-33
------
HP-213
HP-8
HP-10
HP-17
NHP-1003
Glass
Size
Interior
Gasket
Glazing
Adapter
Terminator Horizontal
Clip
Verticle
Clip
Setting
Block
Perimeter
Spacer
3/16"
NHP-30
HP-140
HP-8
HP-8
HP-17
1 /4"
NHP-5A
HP-140
HP-8
HP-8
HP-17
5/16"
NHP-33
HP-140
HP-8
HP-8
HP-17
Glass
Size
Interior
Gasket
Terminator Horizontal
Clip
Vertical
Clip
Setting
Block
OPTIONAL 1" SYSTEM USING HORIZONTALS WITH INTEGRAL WATER DIVERTERS
OPTIONAL 1/4" SYSTEM USING HORIZONTALS WITH INTEGRAL WATER DIVERTERS
NOTE: NHP-5A TO BE USED AS EXTERIOR
GASKET FOR ALL GLAZING INFILLS.
* HP-10 GLAZING CLIP REQUIRED FOR ALL VERTICALS AND HORIZONTALS.
