H P - 1 7 5 / 2 2 5 I N S T A L L A T I O N M A N U A L

1 1/2"

1"

1"

7/8" @

HP-175

1 1/8" @

HP-225

TO

P

O

H F

O

ZI

R

O

AT

N

L

DRILL #17 (.173) Ø

TAP HOLES

HP175-FP-54

HP225-FP-12

SHEAR B LOCK

HP175-FP-55

HP225-FP-13

ANCHOR

FS -43 (#12 X 3/4" PPH)

HP175-FP-56

HP225-FP-14

ANCHOR

HP-10451

7/8" @

HP-175

1 1/8" @

HP-225

7/8" @

HP-175

1 1/8" @

HP-225

OUTSIDE 90° MULLION

FABRICATION
