Page 28
1 13/32"
1"
1"
7/8"
1 1/4"
7/8"
1 1/4"
L
AT
NO
ZI
RO
H F
O
PO
T
DRILL #17 (.173) Ø
TAP HOLES
HP175-FP-54
HP225-FP-12
SHEAR BLOCK
HP175-FP-55
HP225-FP-13
ANCHOR
FS-43 (#12 X 3/4" PPH)
HP175-FP-56
HP225-FP-14
ANCHOR
HP-10468
MULLION
7/8" @
HP-175
1 1/8" @
HP-225
OUTSIDE 90°
BUTT GLAZE MULLION FABRICATION
H P - 1 7 5 / 2 2 5 I N S T A L L A T I O N M A N U A L
28
