31 30
– To reduce the risk of serious injury:
• Do not attempt to disassemble or service the pump or motor; no serviceable parts are
inside. Contact your La-Z-Boy ® dealer for service.
• Check the condition of the power transformers, electrical cords, plugs, and connectors
monthly. Keep the power transformers and electrical cords away from heat sources.
Never operate the unit with a damaged power transformer, electrical cord, plug, or
connector. Contact your La-Z-Boy
® dealer for service.
• The La-Z-Time ® Power units are intended for a single occupant, not exceeding 300 pounds
per seat. Do not operate individual seats or units with more than one occupant in or on
any part of the individual seat or unit.
WARNING
La-Z-Time ® PowerRecline & PowerRecline + Motion
Sofas, Chairs & Motion-Modulars Troubleshooting
If the legrest stops moving while closing, it may have disengaged from the mechanism.
Check the following:
1. Make sure the legrest did not contact an obstruction while closing. Remove any obstruction
from the legrest path.
2. Firmly push the legrest closed with your legs. You will hear a “pop” when the legrest
is reconnected to the mechanism; refer to the Operating Instructions.
If the power recliner does not work, check the following:
1. Make sure the 120 volt power cord is plugged into an electrical outlet.
2. Check the power transformer to make sure the green LED power indicator light is on.
3. Make sure the electrical outlet is working. For example, make sure there are no blown
fuses or tripped circuit breakers.
4. Make sure all the connectors are secure; refer to the Assembly Instructions.
5. Make sure the electrical cords are not crimped or pinched. Make sure the electric cord
or plug is not damaged.
6. Make sure the operating capacity has not been exceeded and there is only one occupant
in the individual seat or unit; refer to the Operating Instructions.
If the power recliner still does not operate properly, contact your dealer for instructions on returning the
unit for examination and repair. Except for the replacement of the power transformer, never attempt to
make any repairs or adjustments yourself.
Power Transformer Replacement
1. Unplug the power transformer from the electrical outlet.
2. Disconnect the 120 volt power cord from the power transformer, and disconnect the power
transformer from the power supply connector; refer to the Assembly Instructions.
3. Connect the new power transformer to the power supply connector behind the unit; push connectors
together until fully seated. Connect the 120 volt power cord to the new power transformer; push the
connectors together until fully seated. Refer to the Assembly Instructions.
4. Install two good quality 9-volt alkaline batteries; refer to Battery Backup Instructions.
5. Plug the 120 volt power cord directly into a wall outlet.
Furniture Placement Guide
& Cup Holder Operating and Cleaning Instructions
– To reduce the risk of serious injury:
• Provide a clear path for operation of the back and legrest. Place tables and area rugs
at a distance to allow the legrest to fully extend without rubbing or interference.
WARNING
To place your reclining unit the proper distance from the wall, fully recline the unit and leave
a minimum of 2" of space between the top of the back and the wall.
Place tables and area rugs at a distance to allow the legrest to fully extend without rubbing
or interference. If necessary, raise the adjustable glides to prevent the legrest from rubbing or
interfering with area rugs; refer to the Assembly Instructions.
To prevent damage to the safety mechanism, do not attempt
to reengage the legrest when it is in the fully open position. NOTICE:
2” Min.
Operating and Cleaning Instructions for the LED Lighted Cup Holder:
Lightly touch the indented circle on the inside of the cup holder with your finger to turn the cup holder light
on and off. No pressure is necessary operate the cup holder light.
The finish on the cup holder can be damaged during use or cleaning. It is recommended that a coaster be
used to reduce the chance for damage, and that the cleaning instructions be followed.
Use water and mild soap, such as dish soap, to clean the cup holders. Dry immediately and thoroughly with
a soft clean cloth to maintain the finish.
The use of harsh, abrasive cleaners is not recommended and must be avoided.
