Boot Setup CP307/CP307-V BIOS Guide
Page 64 ID 35978, Rev. 2.0
P R E L I M I N A R Y
HARD DISK DRIVES SCREEN
This screen will provide a list of hard disk drives if drives are installed in the system. If more
than one drive is installed, this screen also indicates the boot sequence of the drives. Further-
more, this screen provides functions for specifying the BIOS boot order of the drives when more
than one drive is installed.
1
st
Drive, 2
nd
Drive, 3
rd
Drive, etc.
The function 1
st
Drive is used to provide generic information about the currently selected drive
if a drive is installed. If more than one drive is installed, a list of the installed drives is provided,
which allows the selection of one of the listed drives as the 1
st
Drive.
The functions 2
nd
Drive, 3
rd
Drive, etc. are only available when the respective hard disk drives
are installed.
SETTING DESCRIPTION
Not installed When displayed, indicates that there are no drives installed.
When displayed, indicates generic drive information of the 1st Drive.
...
When displayed, indicates the drives installed and their current boot order. Use this
setting to select a new 1st Drive.
