OEM Feature
CP307/CP307-V BIOS Guide
Page 98
ID 35978, Rev. 2.0
P R E L I M I N A R Y
PCI-to-PCI Bridge Reset
SDO
This function is used to perform a PCI-to-PCI bridge reset using a software reset mechanism
prior to configuring the PCI devices on the bus behind the PCI-to-PCI bridge.
Optimal and Fail-Safe default settings: Disabled
cPCI Signal to IRQ5
This function allows the system to select which cPCI signal should be routed to IRQ5.
Optimal and Fail-Safe default settings: Disabled
cPCI Signal to NMI
This function allows the system to select which cPCI signal should be routed to NMI.
Note:
The cPCI Fail signal cannot be routed to IRQ5 and NMI at the same time. No cPCI
signal can be routed to NMI if the Watchdog is selected to NMI.
Optimal and Fail-Safe default settings: Disabled
SETTING
DESCRIPTION
Disabled
Use this setting to disable a PCI-to-PCI bridge reset.
Enabled
Use this setting to enable a PCI-to-PCI bridge reset.
SETTING
DESCRIPTION
Disabled
Use this setting to prevent the cPCI signals from being routed to IRQ5.
cPCI DERATE
Use this setting to select the cPCI DERATE derate signal to be routed to IRQ5.
cPCI ENUM
Use this setting to select the cPCI ENUM derate signal to be routed to IRQ5.
cPCI FAIL
Use this setting to select the cPCI FAIL derate signal to be routed to IRQ5.
SETTING
DESCRIPTION
Disabled
Use this setting to prevent the cPCI signals from being routed to NMI.
cPCI FAIL
Use this setting to select the cPCI FAIL derate signal to be routed to NMI.
