10. Maintenance and Prevention

KISS 2U V2 – User's Guide (Version 1.00)

1

3

2

4

5

6

Fig. 45: Detail without filter mat holder on the front side

Fig. 46: Filter mat holder without filter mat

Fig. 47: Filtermatholder with filter mat

Fig. 48: Filter mat

Legende für Fig. 45 und Fig. 46:

1 Fan slide-in module with bolt with tapped hole

4 Filter mat holder

2 Air intake openings at the front side of the fan slide-

in module

5 Knurled screw of the filter mat holder

6 Positioning latches of the filter mat holder

3 Positioning holes for the filter mat holder

40
