8. Installation and Removal KISS 2U V2 – User's Guide (Version 1.00)
8.4. Installation in a 19" Industrial Cabinet
Expansion card installation should be performed before installing the KISS 2U V2-system into a
19" industrial cabinet.
Please consider the instructions described in the section 8.3 “Accessing Internal Components”.
Before closing the industrial cabinet, you must connect your peripherals to the corresponding system
ports.
For KISS 2U V2 versions and system configurations, please refer to the corresponding
“KISS 2U V2 Systems - Configuration Guides” on our website
www.kontron.com .
More information and technical data can be found in the corresponding board manual (motherboard or
SBC, depending on the system configuration ordered).
You can download the manual from our web site at
www.kontron.com by selecting the product.
Caution:
Energy hazards > 240 VA are present inside the chassis!
The system has to be mounted and installed only by a qualified service person for this area familiar with
the associated dangers.
In order to setting-up, installing / removing the KISS 2U V2 system into/from a 19" industrial cabinet,
please observe the instructions described in this user’s guide.
Please consider the instructions described in the included “General Safety Instructions for IT
Equipment”.
7.2.4 “ Please consider the hints included in the subsection Power Supply Version and ON/OFF Switch of
the PSU”.
The KISS 2U V2 should be installed in a 19" industrial cabinet using slide rails (PN: 1016-5807). Use for
mounting the “Rack Slide Rails Kit for KISS 1U and 2U/4U” (PN: 1051-7200).
Ensure that air flow around the device is adequate when installing the KISS 2U V2.
The openings for air intake and exhaust on the device must not be obstructed by objects.
Leave at least 5 cm (approx. 2") of free space to the 19" industrial cabinet in front and behind the
KISS 2U V2, to prevent the device from possibly overheating.
The 19" industrial cabinet must stand firmly in place. You can improve its stability by placing the
components into it from the bottom up. Heavy components should be placed down below.
If further stabilization is necessary, then bolt the 19" industrial cabinet to the floor or anchor it on the
wall.
The voltage feeds must not be overloaded.
Adjust the cabling and the external overcharge protection to correspond with the electrical data
indicated on the type label.
The type label is located on right side of the unit.
