7. Product Description KISS 2U V2 – User's Guide (Version 1.00)
7.6.1. Riser Card and/or Backplane and available Bays
Depending on the KISS 2U V2 hardware configuration ordered, you can expand your system with full size and/or half size
or low-profile additional cards.
System Installed Board Riser Card /Backplane Available Slots for Exoansion Cards
Riser card 1 2x PCI, 32 Bit @ 33 MHz, full size
1x PCI, 32 Bit @ 33 MHz, full size
Riser card 2
1x PCIe x16, full size
1x PCIe x16 full size
Riser card 3
1x PCIe x4 full size
Desktop
Motherboard
1x PCIe x16 (for low-profile cards only)
without riser card 1x PCIe x4 (for low-profile cards only)
2x PCI, 32 Bit @ 33 MHz, (for low-profile cards only)
Server Motherboard without riser card 4x PCIe x8 (for low-profile cards only)
KISS-2U V2
3x PCI, 32 Bit @33 MHz (1. side)
Backplane 1 1x PCIe x16 (2. Side)
1x PCIe x4 (2. Side)
SBC 2x PCIe x4 (1. Side)
1x PCIe x4 (2. Side)
Backplane 2
1x PCIe x16 (2. Side)
1x PCIe x8 (2. Side)
