Software Setup
74 AT8242
www.kontron.com
5.1.1.7 Bootloader Network Interfaces
The following table represents the logical u-boot network interfaces related to their physical Cavium NPU
connection (QLM):
5.1.2 OCTEON-SDK Board Support Package
5.1.2.1 Installation
5.1.2.1.1 Requirements
- Host with Linux operating system.
- Full installation of OCTEON SDK.
- Latest board support package from Kontron.
5.1.2.1.2 Instructions
1 - First of all, perform the full installation of Octeon SDK by following official Cavium instructions, the
Octeon SDK version that needs to be installed is specified in README document of AT8242 Board support
package.
2 - After installing the official OCTEON SDK, install the patch bundle from the board support package:
Copy the patches directory from the board support package to the root of the Octeon SDK.
Install the patch bundle included in board support package, two options are available:
OPTION 1: Using quilt utility
From the root of the Octeon SDK execute quilt utility:
# quilt push -a
OPTION 2: Using shell command line
From the root of the Octeon SDK type:
# for i in $(cat ./patches/series); do patch -p1 < ./patches/$i;done
Cavium physical interfaces (QLM) u-boot logical name(s)
RXAUI/QLM0 octeth0, octeth1
DXAUI/QLM2 octeth2
SGMII/QLM3 octeth3, octeth4, octeth5, octeth6
XAUI/QLM4 octeth7
