Kontron AT8242 User Manual
Page 58
42
www.kontron.com
11
RTM Power
Threshold
FRU 3 (RTM) Power consumption in watts
Sensor type = 0Bh Other Unit-Based Sensor (Watt)
Event Reading type code = 01h threshold base
See IPMI v1.5 section 29.13.3 for threshold based event
12
Vcc +12V SUS
Threshold
Voltage on board 12V suspend (management) power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
13
Vcc +5V SUS
Threshold
Voltage on board 5V suspend (management) power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
14
Vcc +3.3V SUS
Threshold
Voltage on board 3.3V suspend (management) power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
15
Vcc +2.5V SUS
Threshold
Voltage on board 2.5V suspend (management) power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
16
Vcc +1.5V SUS
Threshold
Voltage on board 1.5V suspend (management) power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
17
Vcc +1.2V SUS
Threshold
Voltage on board 1.2V suspend (management) power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
18
Vcc +0.75V SUS
Threshold
Voltage on board 0.75V suspend (management) power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
19
Vcc +1.2V Early
Threshold
Voltage on board 1.2V early power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
20
Vcc +5V
Threshold
Voltage on board 5V payload power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
21
Vcc +2.5V
Threshold
Voltage on board 2.5V payload power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
22
Vcc +1.1V
Threshold
Voltage on board 1.1V payload power supply (Volts)
Sensor type = 02h voltage
Event Reading type code = 01h threshold based
See IPMI v1.5 section 29.13.3 for threshold based event
ID
Sensor Name
Sensor Class
Description (Sensor Type, Event trigger)
