4.5 OEM Sensor Tables
Table 4-46:Power Good Sensor
Table 4-47:Firmware Info 1 sensor
Table 4-48:Firmware Info 2 sensor
Event/Reading Type Code Sensor Type Sensor Specific Offset Event Trigger
77h
OEM Kontron
ATCA Power Good
08h
Standard IPMI
Power Supply
00h Unused
01h 5V
02h 3.3V
03h 2.5V
04h Unused
05h 1.5V
06h 1.2V
07h Vcore
08h Unused
09h 1.1V
10h 1.05V
11h Unused
12h Unused
13h Vddq
14h Unused
15h Unused
Event/Reading Type Code Sensor Type Sensor Specific Offset Event Trigger
70h OEM Kontron
Firmware Info 1
C0h
OEM Kontron
Firmware Info
00h
Event Code Assert
Trigger
01h
Event Overflow Trig-
ger
02h to 0Eh
Code Assert Line
(Binary Encoded)
0Fh Unused, Reserved
Event/Reading Type Code Sensor Type Sensor Specific Offset Event Trigger
75h OEM Kontron
Firmware Info 2
C0h
OEM Kontron
Firmware Info
00h
Event Code Assert
Trigger
01h Unused Trigger
02h to 09h
Code Assert File Id
(Binary Encoded)
0Ah to 0Fh Unused, Reserved
