2.5 Serial Interfaces
The AT8242 uses serial interfaces to manage the NPU0, NPU1 and the P2010. Since no video interface is
provided on board, the only way to get visual information on the board is the serial console. They are 16C550
high-speed UART compatible and support 16-byte FIFO buffers for transfer rates from 9.6Kbps to 115.2Kbps.
The default Serial port speed for OS shell access is 115.2 kbps.
Table 2-3:Serial Interface connector Pinout
3
14
56 XFI/SFI/KR 1/10GbE RTM - SFP+5
57 XFI/SFI/KR 1/10GbE RTM - SFP+6
58 XFI/SFI/KR 1/10GbE RTM - SFP+7
59 XFI/SFI/KR 1/10GbE RTM - SFP+8
15
60
RXAUI 10GbE NP0 - QLM0_0
61
62
RXAUI 10GbE NP0 - QLM0_1
63
16
64
DXAUI 20GbE NP0 - QLM2
65
66
67
17
68
N/C
69
70
71
Pin Signal
1 RTS
2 DTR
3 TX#
4 GND
5 GND
6 RX#
7 DSR
8 CTS
Group Warpcore Lane# Port Setting Speed Physical Connection
