60 AT8242
www.kontron.com
4.4.2 MMC sensors
Table 4-41:MMC Sensors
Initiate Upgrade Action 3-8 PICMG 31h No
Upload Firmware Block 3-9 PICMG 32h No
Finish Firmware Upload 3-10 PICMG 33h No
Get Upgrade Status 3-2 PICMG 34h No
Activate Firmware 3-11 PICMG 35h No
Query Self-Test Results 3-12 PICMG 36h No
Query Rollback Status 3-13 PICMG 37h No
Initiate Manual Rollback 3-14 PICMG 38h No
ID Sensor Name Sensor Class Description (Sensor Type, Event trigger)
0 IPMI Info-1 Discrete
Internal Management Controller firmware diagnostic
Sensor type = C0h Kontron OEM Firmware Info
Event Reading type code = 70h Kontron OEM Internal Diagnostic
See OEM table, Sensor type code C0h and Event/Reading type code 70h for
sensor definition
1 IPMI Info-2 Discrete
Internal Management Controller firmware diagnostic
Sensor type = C0h Kontron OEM Firmware Info
Event Reading type code = 75h Kontron OEM Internal Diagnostic
See OEM table, Sensor type code C0h and Event/Reading type code 75h for
sensor definition
2 FRU Agent Discrete
FRU Information Agent - FRU Data Error Detection
Sensor type = C5h Kontron OEM FRU Info Agent State
Event Reading type code = 0Ah Generic Discrete, offset 6,8 are used
See OEM Table, Sensor Type code C5h for sensor definition
3 ModuleHotSwap Discrete
Module Hot-Swap
Sensor type = F2h Module Hot-Swap
Event Reading type code = 6Fh Sensor specific, offset 0,1,2,3,4 are used
See AMC.0 R2.0 Section 3.6.6 Module Hot Swap Sensor for sensor definition
4 MMC Stor Err Discrete
Management sub-system health: non volatile memory error.
Sensor type = 28h Management Subsystem Health
Event Reading type code = 6Fh Sensor specific, only offset 1 is used
See IPMI v1.5 table 36.3, Sensor type code 28h for sensor definition
5 IPMI Watchdog Discrete
IPMI Watchdog (payload watchdog)
Sensor type = 23h Watchdog 2
Event Reading type code = 6Fh Sensor specific, offset 0,1,2,3,8 are used,
See IPMI v1.5 table 36.3, Sensor type code 23h for sensor definition
6 CPU Reset Discrete
Board reset type and sources
Sensor type = CFh OEM (Kontron Reset Sensor)
Event Reading type code = 03h Digital Discrete offset 0,1 are used
See OEM sensor table, Sensor type code CFh for sensor definition
IPMI Spec. section NetFn CMD IPMI BMC req. Module MMC
req. Kontron support
on MMC
