3.3.1
Memory List and Characteristics
Table 3-1:Approved Memory List
Memory should have the following characteristics:
• DDR3 1333
• 1.5V
• Single or dual-rank modules are supported
• x8 memory with up to 2 ranks per DIMM
• Unbuffered & ECC
• Very Low Profiles (VLP) 0.72inches maximum heights (18.3mm)
The NPU's DDR3 speed is set by default to 1066; the procedure to change it can be found under: “U-boot
Memory Configurations” on page 72.
Manufacturer Part Number
Description
Company
VL31B5263E-K9S
4GB 512Mx72 DDR3 SDRAM VLP ECC UNBUFFERED
DIMM 240-PIN
VIRTIUM TECHNOLOGY
WARNING
Because static electricity can cause damage to electronic devices, take the following
precautions:
Keep the board in its anti-static package, until you are ready to install memory.
Wear a grounding wrist strap before removing the board from its package; this will
discharge any static electricity that may have built up in your body.
Handle the board by the faceplate or its edges.
