CP383
Configuration
ID 27784, Rev. 01
© 2004 Kontron Modular Computers GmbH
Page 4 - 15
27784
.01.VC.040308/162544
P R E L I M I N A R Y
Note ...
The board will continue issuing an interrupt until all interrupt sources are han-
dled completely and no interrupt condition remains.
Table 4-17: General Interrupt Enable Register
BITS
TYPE
DEFAULT
FUNCTION
31
r/w
0
Board Interrupt Enable
30 - 0
r/w
0
Reserved
Note ...
A set bit means that the board’s interrupt is enabled.
Table 4-18: General Interrupt Pending Register
BITS
TYPE
DEFAULT
FUNCTION
31
r/w
0
Board Interrupt Pending
29 - 0
r/w
0
Reserved
Note ...
A set bit means that the board’s interrupt is pending. A board interrupt must be
cleared by writing a "1" to the corresponding output irqen event flag.
Table 4-19: Output Status Register
BITS
TYPE
DEFAULT
FUNCTION
31
r
0
Fail
30
r
0
Diag
29 - 0
r
0
Reserved
Table 4-20: Input IRQ Register
BITS
TYPE
DEFAULT
FUNCTION
31
r/w
0
Not used
30
r/w
0
Input compare interrupt enable
29 - 0
r/w
0
Input event interrupt enable
