4.4 Programming Interface
4.4.1 Access Control Logic (Address Decoder)
All the resources of the CP383 are mapped within the 64 kB PCI memory address space which
itself is set in the PCI configuration register BAR0. The port size of all local or backend registers
is 32-bit by default. The address map of the registers is as follows.
Table 4-1: Backend Register Address Map
BASE ADDRESS
(BAR0)
SIZE FUNCTION
+ 0x0000 4 kB COMMON BOARD REGISTER
0x0400 32 bit g_irq General Interrupt Enable Register
0x0800 32 bit hsr Hardware Status Register
0x0804 32 bit i_pen General Interrupt Pending Register
0x0C00 32 bit hdr Hardware Debug Register
+ 0x1000 4 kB CAPABILITY ROM, SERIAL EEPROM
0x1000 32 bit r_cmd Command Register
0x1400 32 bit r_ctl Control Register
0x1800 32 bit r_sta Status Regsiter
0x1C00 32 bit r_dat Data Register
+ 0x2000 4 kB DIGOUT A CLUSTER
0x2400 32 bit o_ctl_a Output Control Register
0x2800 32 bit o_sta_a Output Status Register
0x2C00 32 bit o_dat_a Output Data Register
+ 0x3000 4 kB DIGOUT B CLUSTER
0x3400 32 bit o_ctl_b Output Control Register
0x3800 32 bit o_sta_b Output Status Register
0x3C00 32 bit o_dat_b Output Data Register
+ 0x4000 4 kB DIGIN CLUSTER
0x4400 32 bit i_ctl Input Control Register
0x4408 32 bit i_irquen Input Irq Enable Register
0x440C 32 bit e_pol Input Event Polarity Register
0x4410 32 bit e_msk Input Event Mask Register
0x4414 32 bit e_len Input Latch-on Event Register
0x4418 32 bit c_cmp Input Pattern Compare Register
