Introduction CP383
Page 1 - 12 © 2004 Kontron Modular Computers GmbH ID 27784, Rev. 01
27784
.01.VC.040308/162542
P R E L I M I N A R Y
1.7 Software Support
The CP383 is supplied with appropriate driver software which provides software interfacing to
the System Master. The CP383 supports Windows XP
 , Windows NT 4.0  , Windows 2000  ,
VxWorks  and Linux  .
1.8 Applied Standards
The Kontron Modular Computers’ CompactPCI systems comply with the requirements of the
following standards:
Signal Output
Overcurrent Protection For output currents of greater than 0.8 A, the output will be switched to a fail-
ure mode: square wave signal with a maximum current amplitude of 0.4A and
an on/off time (t
on,
t
off
) of 100 µs.
This type of system failure indication is made available to the DIO ProComm
Controller.
Undervoltage Protection for
external power supply For the voltage source (EXTVCC) <= +8.5V, the outputs are switched off.
This type of system failure indication is made available to the DIO ProComm
Controller.
Overtemperature If the case temperature of the High Side Driver switches exceeds 150°C, the
outputs are switched off.
This type of system failure indication is made available to the DIO ProComm
Controller.
Isolation 2 kV process to system
Table 1-6: Applied Standards
TYPE STANDARD
CE
Emission EN50081-1
Immunity, Industrial Environment EN61000-6-2
Immunity, IT Equipment EN55024
Electrical Safety EN60950
MECHANICAL Mechanical Dimensions IEEE 1101.1
ENVIRONMENTAL TESTS
Vibration, Sinusoidal IEC60068-2-6
Random Vibration, Broadband IEC60068-2-64 (3U boards)
Permanent Shock IEC60068-2-29
Single Shock IEC60068-2-27
Climatic Humidity IEC60068-2-78
Table 1-5: CP383 Digital Output Specifications (Continued)
TYPE DESCRIPTION
