CP383 Introduction
ID 27784, Rev. 01 © 2004 Kontron Modular Computers GmbH Page 1 - 5
27784
.01.VC.040308/162542
P R E L I M I N A R Y
The following table provides a quick overview of the CP383 board.
1.3 Board Overview
1.3.1 Board Introduction
The CP383 is a digital input and digital output board which provides 32 channels grouped into
one digital input cluster consisting of 16 channels and two digital output clusters consisting of
8 channels each.
Table 1-1: CP383 Product Overview
CP383 FEATURES DESCRIPTION
Digital Input and Output
Board • CompactPCI: 3U, 4HP
• 33 MHz system clock
• 32-bit address and data bus
• Designed for Plug and Play
• Complies with the CPCI specification
Digital Input Channel • Input Signals: Voltage range:low: -3V to +5V
high: +11V to +30 V (+24V standard)
Maximum current: 5 mA
• Channel Isolation: The input channels are isolated from the system side and do
not share common GND or VCC.
• Output Data: A maximum of 16 measured digital values
Interrupt messages (optional)
Programmable registers (read / write, compare, event and
latch)
• Debouncing: Range of settings available: 33 MHz, 128 kHz, 32 kHz, 8 kHz,
2 kHz, 500 Hz, 125 Hz, 31 Hz (30 ns default)
Digital Output Channels 16 digital output channels in 2 independent clusters of 8 channels each. Each clus-
ter may be set to operate at different voltages for different loads within the pre-
scribed output voltage limits. The output is realized via the HSD switches.
The output channels are isolated from the system side and share common GND and
VCC within the clusters. The two output clusters are galvanically isolated from each
other.
External Interfaces 2 external interfaces, the digital input and output interface connector CON2 on the
front panel and a single CompactPCI connector at the rear.
The digital input and output interface connector supports up to 16 digital input and
16 digital output channels. The connector pins are subdivided into 3 clusters or
groups.
The CompactPCI connector is the standard CPCI type connector for CON1.
Indicators One green LED (Run) and one red LED (Fail), which are user configurable
Temperature Range The board is qualified to operate over a wide range of temperatures as follows:
• Operational:
0ºC to +60ºC Standard
-40ºC to +85ºC E2
• Storage: -55ºC to +125ºC
