KPA3 Connector Replacement
Page 7 of 16
At the opposite end of the rear panel are one or two SO-239 “UHF” antenna connectors, depending upon
whether you have the KAT3 ATU installed. Directly behind the ANT connectors are one or two pin connectors to
the pc board (see Figure 11). Use your needle nose pliers to unplug the connector(s).
Figure 11. Unplugging the ANT Connectors.
Remove the hardware shown in Figure 12 to free the rear panel and set it aside.
Figure 12. Removing the Rear Panel.
You can leave the KXV3 board (Figure 9) in place or unplug it at this time. If left in place, be careful that
you don’t dislodge it accidentally.
