7

ILLUSTRATION DESCRIPTION

QTY.

ELECRAFT

PART NO.

Rear Shield

1

E100217

Screw, 4-40, 1/4” (6.4 mm) Zinc, Pan
Head

9 E700005

Screw, 4-40, 1/4” (6.4 mm) Black, Pan
Head

1 E700009

Screw, 4-40, 3/8” (9.5 mm) Black, Flat
Head

1 E700131

Screw, 4-40, 7/8” (22 mm ) Black, Flat
Head

8 E700159

Acorn Nut, 4-40

8

E700160

Standoff, 4-40, 5/16” (7.9 mm) long

1

E700121

Lock Washer, #4 Inside Tooth

4

E700010

Lock Washer, #4 Split

4

E700004

Nut, 4-40

1

E700011

Installation Procedure

K3 KIT BUILDERS:

If you were directed here to install the KPA3 module as part of the initial

K3 assembly, begin here to complete the installation. Skip over the steps indicated.

Disconnect power and all cables from your K3.
