3 - 10 Document #98234100
The Outrigger can now swivel into the lock
channel on the deck to secure it for making runs
or swivel neatly under the deck to get it out of the
way, when not in use.
Step 2
Using the 3/8" x 2
1/
2" Hex Bolts, Flat Washers
and Nylon Lock Nuts, bolt the carriage to the left
front deck.
Place the lid over the open drum and secure it
with two retainer pins.
Warning: When using the motorcycle carriage
option, install the safety cover on the
open drum.
Open drum
Retainer Pin
