Removing the Dyno from the Crate
You will have to provide equipment capable of lifting a
minimum of 1600 lbs. (725 kg.) to lift the dyno off the
crate and position in your dyno room. You will also
need a pair of straps capable of supporting 1600 lbs.
(725 kg.) to attach to the dyno (Dynojet recommends
the single loop style straps). Use the following steps to
remove the dyno from the crate.
Step 1
Lift the top plate out of the crate and set it aside.
Step 2
Loop two straps around the dyno axle as shown in
the picture on the next page: Lift the dyno off the
crate and position it in the dyno room.
Warning: Loop the straps as close to the drums as
possible. Take extra care when lifting the
dyno that the straps don’t come in
contact with the sensitive electronics
attached to the dyno.
