163
(5) Channel Settings
The numbers from 01 to 16 represent the camera ID. In Transmitting Channels section, enable the
camera number to receive the camera signal from the server. In Visible Channels section, enable the
camera number to view the camera signal on Remote Console screen. To select all the cameras,
enable the ALL check box.
5.3 Familiarizing the Buttons in PTZ Camera Controller
Name Function
(1) Close Exit PTZ camera controller.
(2) Setup Configure PTZ cameras.(also see Chapter 4.13 )
(3) AutoPan Operate the PTZ cameras automatically based on the selected camera
group preset position number.
(4) Focus +/- Adjust the focus manually to produce clear image.
(5) Zoom +/- Zoom in and out the image.
(6) Direction buttons Adjust and position the focal point of the PTZ camera.
(7) Camera ID pane Display the PTZ camera number that is being operated.
(8) Camera lens
speed controller
Adjust the moving speed of the PTZ camera lens.
(9) Camera preset
position number
Move the PTZ camera to the preset point.
(10) Group AutoPan Select to automatically operate PTZ camera in group.
